RRD
Version E
| RRD051E | RRD061E | RRD081E | RRD101E | |
|---|---|---|---|---|
| Plate capacity | 10ø 200-260 - 5ø 270-320 | 12ø 200-260 - 6ø 270-320 | 16ø 200-260 - 8ø 270-320 | 20ø 200-260 - 10ø 270-320 |
| Tray capacity | 5 GN1/1 | 6 GN1/1 | 8 GN1/1 | 10 GN1/1 |
| Product capacity | 18 Kg | 22 Kg | 29 Kg | 36 Kg |
| Tray Runners Pitch | 93 mm | 78 mm | 96 mm | 76 mm |
| Dimensions mm | 880x815x1340 h | 880x815x1340 h | 880x815x1640 h | 890x815x1640 h |
| Weight | 135 Kg | 135 Kg | 159 Kg | 159 Kg |
| Electric power | 3450W | 3450W | 6800W | 6800W |
| Power supply | AC 220-240V 50Hz | AC 220-240V 50Hz | AC 380-415V 3N 50Hz | AC 380-415V 3N 50Hz |
| Spec sheet | Download | Download | Download | Download |
| RRD153E | |
|---|---|
| Plate capacity | 64ø 200-260 - 32ø 270-320 |
| Tray capacity | 16 GN1/1 - 32 GN 1/1 |
| Product capacity | 115 Kg |
| Tray Runners Pitch | 72 mm |
| Dimensions mm | 1000x855x1980 h |
| Weight | 180 Kg |
| Electric power | 10150 W |
| Power supply | AC 380-415V 3N 50Hz |
| Spec sheet | Download |
 |
The temperature is adjustable from +30°c to +160°c on the GRE-RRO-RRT-RRFF-RRFT models. |
 | The temperature is adjustable from +0°c to +160°c on RRD-RRFC models. |
 | The manual regeneration cycle procedure offers all the traditional convenience to the chef's work (on all versions). |
 | The electronic control is very intuitive and easy to use even by less experienced personnel (d and e versions). |
 |
The recipe book is always customizable and easily navigable (only on the e version). |
 | The automatic regeneration programs divided into 4 product categories are the perfect starting point for your experience with a retherma regenerator (e version only). |
 | The favorite programs section allows the chef to automatically reuse pre-set recipes (only on version e). |
 | The retherm programs can be divided into 9 different steps and allow high precision in food regeneration (only on the e version). |
